FG Throttle-brake servo T1005 FG6598

This FG throttle-brake servo is supplied as standard servo in all RTR models.

Sturdy servo with steel gears. The output shaft has 25 teeth.

Technical data:

• Torque at 6.0 V: 9.0 kg-cm
• Speed at 6.0V: 0.14 sec/60 degrees
• Torque at 7.4 V: 10.0 kg-cm
• Speed at 7.4V: 0.12 sec/60 degrees
• Voltage: 6.0 ~ 7.4 DC Volts
• Cable length: L30 cm
• Weight: 56 grams
• Servo arm: 25T
• Ball bearings: Yes 2 x
• Gear type: Steel
• Operating Temperature: -20℃~60℃
• Dimensions: L40.8-W20.1-H38mm
