Fujiwara Zenoah Tuning Carburetor Ø15 mm FKT3002

New from Fujiwara is this powerful large-bore Venturi carburetor for the Fujiwara 35.2cc Zenoah G320 32cc engines. This carburetor is based on a carburetor similar to the Walbro WT-1107 used in the G320 series engines, but with a massive 15mm venturi diameter to further increase engine power. The design of this carburetor is aimed at smoother acceleration and a more powerful RPM, particularly in the mid- to high RPM range.

This carburetor is supplied as pictured, including carburetor and gasket. Although this carburetor was originally intended for use with the Zenoah Fujiwara G350RC, it is also suitable for engine builders and tuners looking for a new power source for their engines with a WT carburetor. This carburetor is a good choice for riders with a displacement of 34cc to 39cc. The choke lever is not included; you can order it separately.

When choosing a tuning version, i.e., with bearings and/or a RVS340 steel shaft, the carburetor is also vacuum-tested and optimally tuned.

Explanation of throttle valve shaft options

• With standard throttle valve shaft
• With ball-beared standard throttle valve shaft
• With Stainless steel 340 throttle valve shaft
• With ball-beared Stainless steel 340 throttle valve shaft, (recommended)

Default settings:

• Stationary screw: 2 turns
• Lower mixing screw (L) one and a quarter turn open
• Upper mixing screw (H) one and a quarter turn open

Specifications:

• Bore: Ø15,9 mm
• Venturi: Ø18,6 mm

Suitable for all engines in our program and similar types.
