JXB130 Brushless Mega Power Servo

The JX2070 was a true revolution in price compared to performance and longevity. JX goes one step further with this B130 Brushless!

The housing is made entirely of CNC machined 7075ST aluminum, which significantly improves cooling, precision and also the lifespan. The three aluminum parts and output shaft are sealed with O-rings. Equipped with the latest state of Micro electronics and Brushless motor. The thick steel gears with bearings make the whole thing a real powerhouse.

Many customers with the experience of the JX2070MG will certainly be very satisfied with this JX-B130!

We are also the only one within Europe to provide an original factory warranty for 6 months and all parts are available from stock!

Specification:

• Torque at 6.0 volts: 92 kilos
• Speed at 6.0 volts: 0.10 sec/40 degrees
• Torque at 7.4 volts: 107 kilos
• Speed at 7.4 volts: 0.09 sec/40 degrees
• Torque at 8,4.volts: 130 kilos
• Speed at 8,4 volts: 0.08 sec/40 degrees
• Dimensions: L66 x W30 x H59 mm
• Cable length: 30 cm-10,43 inch
• Stekker: Universal (JR & Futaba)
• Splash waterproof
• Ball beared
• Special metal gears
• Servo lever: 15 teeth
• Servo lever thread mount: M3
• Weight: 260 grams

In terms of installation dimensions equal to the JX2060, JX2070, Spektrum S9110, Spektrum S9120, Savox S0235, S0236, S0240, S0241, etc,

The voltage may vary between 6.0 and 8.4 volts, so can be used with 5 cell NiCd, NiMh, or 2S Li-Fe or 2S Li-Po battery. We recommend, when using older type receiver with BEC system, to power this JXB130 Power Servo directly from the receiver battery. For this direct power supply we have a special splitter in our program, TPS0528.

With us with 6 months original factory warranty with the exception of the gears
